Pure sine wave output
DC Start & automatic self-diagnostic function
Automatically send signal to start generator
High efficiency design for optimized battery performance
Selectable charging current based on applications
lead acid battery/Lithium battery
AC start-up voltage auto restart voltage/110V/120V Output Available
| Model | VS1312P |
| AC Input voltage | 220VAC(standard) |
| Input voltage range |
154-264VAC±5V(Nor
Model) 185-264VAC±3V(UPS Model) |
| Input frequency | 50/60Hz±5% |
| Out put power |
1300VA 1000W |
| AC model output voltage | 220V±10% |
| Battery model output frequency | The output frequency under the mains is the same as the input frequency |
| Battery model output voltage | 220VAC±3% |
| Battery model output frequency | 50HZ or 60HZ±1% |
| Battery model output wave | Pure sine wave |
| Battery type | External lead-acid battery,Gel battery, water battery or Lithium battery |
| Battery voltage | 12/24VDC |
| Battery charging voltage | 13.7/27.4VDC |
| Maximum PV array power | 12V:800W 24V:1600W |
| Solar input voltage range |
12V:PWM 15V-50VDC 24V:PWM 30V-105VDC |
|
Maximum PV display open circuit voltage |
12V:PWM 50VDC 24V:PWM 105VDC |
| Maximum solar charging current | 60A |
| Maximum AC Charge Current | 40A/20A |
| Battery charging voltage range | 154-275VAC±5V |
| Transfer time | ≤10ms(UPS Model)/≤20ms(INV Model) |
| load peak ratio | (MAX)3:1 |
| Protective function |
Under
the mains input overcurrent fuse Under inverter:overload protection,short circuit protection,low voltage protection, (with battery anti-reverse connection,board). |
| Status display | You can view parameters such as AC voltage,AC freguency,PVvoltage,PV current,output voltage output frequency,battery voltage,load current and other parameters by turning the page keys. |
| Voice prompt |
Low
battery protection buzzer long beep Low battery buzzer beeps every second Machine fault buzzer beeps Overload buzzer beeps When the overload is less than 130%,the buzzer will sound every second.and the output will be turned off after 30S.When the overload is greater than150%,the output will be turned off after 300ms. |
| Operating temperature | -10℃~50℃ |
| Storagetemperature | -15℃~45℃ |
| Relative temperature | -10℃~90℃ no condensation |
| Noise | <45dB |
We answer most inquiries in less than 3 hours during our normal business hours.
Categories
Lithium battery auto-restart function more convenient forlithium battery charging Intelligent power supply mode,intelligent distribution of solarpanel/mains/battery power shares Utility charging voltage/PV charging voltage adjustablematch different battery charging requirements Slim body, convenient installation and transportation Battery reverse connection protection with fuse switch,safer installation PF1.0, high efficiency, lower consumption,energyconservation/environmental protection/electricitysaving/cost saving Support working without battery: reduce solar system cost High precision of output voltage,±5%, take care of yourappliances Communication option: external WlFl, supervise at any time BMS function for lithium battery
Lithium battery auto-restart function more convenient forlithium battery charging Intelligent power supply mode, intelligent distribution of solarpanel/mains/battery power shares Utility charging voltage/PV charging voltage adjustablematch different battery charging requirements Slim body, convenient installation and transportation Battery reverse connection protection with fuse switch.safer installation PF1.0, high efficiency, lower consumption,energyconservation/environmental protection/electricitysaving/cost saving Support working without battery: reduce solar system cost High precision of output voltage,±5%, take care of yourappliances Communication option: external WlFl, supervise at any time BMS function for lithium battery
Lithium battery auto-restart function more convenient forlithium battery charging Intelligent power supply mode, intelligent distribution of solarpanel/mains/battery power shares Utility charging voltage/PV charging voltage adjustablematch different battery charging requirements Slim body, convenient installation and transportation Battery reverse connection protection with fuse switch.safer installation PF1.0.hiah efficiency,lower consumption,energyconservation/environmental protection/electricitysaving/cost saving Support working without battery: reduce solar system cost High precision of output voltage,+5%, take care of yourappliances Communication option: external WlFl, supervise at any time BMS function for lithium battery
Lithium battery auto-restart function more convenient forlithium battery charging Intelligent power supply mode, intelligent distribution of solarpanel/mains/battery power shares Utility charging voltage/PV charging voltage adjustablematch different battery charging requirements Slim body, convenient installation and transportation Battery reverse connection protection with fuse switch.safer installation PF1.0, high efficiency, lower consumption,energyconseryation/environmental protection/electricitysaving/cost saving Support working without battery: reduce solar system cost High precision of output voltage,±5%, take care of yourappliances Communication option: external WlFl, supervise at any time BMS function for lithium battery
Lithium battery auto-restart function more convenient forlithium battery charging Intelligent power supply mode, intelligent distribution of solarpanel/mains/battery power shares Utility charging voltage/PV charging voltage adjustablematch different battery charging requirements Slim body, convenient installation and transportation Battery reverse connection protection with fuse switch,safer installation PF1.0, high efficiency, lower consumption,energyconservation/environmental protection/electricitysaving/cost saving Support working without battery: reduce solar system cost High precision of output voltage,+5%, take care of yourappliances Communication option: external WlFl, supervise at any time BMS function for lithium battery
